Photovoltaic Module TRIxxxSP-RR MWT 60 cells RED

Residential

Photovoltaic Module TRIxxxSP-RR MWT 60 cells RED

  ACCESS THE CONFIGURATOR

The Trienergia TRIxxxSP-RR modules are new generation red solar panels suitable for systems connected to the electricity grid.

Design

Ideal for installations with high aesthetic value.

Guaranteed

Product guaranteed for 20 years.

High performance

12-year 90% performance guarantee.

Technical information

TRIxxxSP-RR
Ideal for systems with high aesthetic value
60 M6 CELLS - (166 x 166mm)

Rectangular MonoPERC Photovoltaic Module

Dimensions: 1712 x 1035 x 35 mm

Weight: 20kg

Color: Red RAL8015 (tile / brick color)

Red anodized aluminum frame

JunctionBox TIGO IP67

Compatible MC4 connectors
Product guarantee: 20 years
Performance guarantee: 12 years at 90% |  30 years at 82%
Certificates: IEC 61215 – IEC 61730/1 – IEC 61701 – FIRECLASS 1

*25 Years warranty only for Green Specialist GOLD installers

Additional Information

The production process, completely automatic, provides:
  1. Positioning of the conductive backsheet made with EBfoil® BYS, which acts as a contact and connection for the positive / negative contacts on the back of the solar panel
  2. Laying of the cells that make up the photovoltaic module: these are glued on the backsheet by the silk-screen dispensing of a special conductive glue; at the same time a quality control is performed on the cells:
    – Chipping: chipping on the edge of the cell
    – Breakage: cell breakage
    – Microcrack: cell micro-perforation not visible to the naked eye
    – Positioning: positioning of the cell
  3. Application of an EVA (ethylene vinyl acetate) sheet, very flexible and elastic, which encapsulates the cells with the backsheet
  4. Glass application
  5. Flipping, rotation of the module to enter lamination resting on the glass
  6. Panel lamination
  7. Framing, assembly of the frame
  8. Tests: solar simulator and electroluminescence
Available model:
  • TRI320SP-RR

In terms of performance, 90% efficiency is guaranteed for up to 12 years and 82% for up to 30 years of use.

The panels are assembled in the Trienergia factory in the province of Mantua.

The sale of these black photovoltaic modules is mainly aimed at installers, designers and wholesalers. To find out the cost, simply request a free quote by filling out the form in the "Request a free quote" panel.
